MYDL354
BOEEP
MYDL
Product Description
BOEEP volute sludge extruder which uses the screw ectrusion principle to separate solide and liquid is a new type separation device. It reaches the purpose of dewatering sludge by the powerful extrusion pressure of changing the screw diameter and distance, and the tiny spacing between moveable annular plates and fixed annular plates.
Overall Structure
The screw body, driving device, filtrate receiver, mixing system and frame consist the volute sludge extruder.
The main body is made of multiple fixed annular plates and moveable annular plates with the screw shaft running through it. The front part is thickening part and the ending part is dewatering part. It can thicken and dewater sludge in one chamber.
Flow Chart
Sludge will be transported to the dehydration part after being thickened in the thickening part. In the advancing process, great pressure has been produced because of the gradually decreasing filter spacing and screw distance with the clogging of the back platen. Then the volume decreases continuouly, and the purpose of fully dewatering will be achieved.
Function
Application
BOEEP volute sludge extruder can be widely used to dewater sludge of municipal administration wastewaterr, tannery and pharmaceutical, papermaking, petrochemical engineering, printing, slaughtering and breeding, food, drink, ect.
Advantages
Low energy consumption.
Minimal water consumption.
Minimal noise.
Low polymer consumption.
No need for proceeding sludge thickening.
Suitable for any type of sludge even suitable for dewatering oil/grease rich sludge.
Minimal maintenance and operational cost.
Capable for working 24/7.
Technical Parameters
| Parameter | |
| Type：MYDL354 | Dimension：L4700×W2710×H2130(mm) |
| Solid content：10000~50000mg/L | Capacity：400-480kgds/h |
| Power：5.9kw | Protection Level：IP55 F |
| Power Supply：380V/3/50Hz | Output sludge moisture content：75-85% |
| Polymer feeding rate：DS 0.2～1% | Flush water：280L/h |
| Water supply pressure：≥0.2MPa | |
| Screw body | Flocculated mix tank |
| Specification × Length：Φ350×2800(mm) | Dimension：L2000×W1000×H1150(mm) |
| Quantity：4 | Volume：About 2300L |
| Material：Plate: SUS304/ Screw Shaft: SUS304 | Material：SS304 |
| Motor Power：1.1×4kW | Motor power：0.75x2kw |
| Electrical Cabinet | |
| 1. Frequency converting controls dewatering body; | |
| 2. Controls polymer mixing device; | |
| 3. Realize the switch of automatic operation and manual operation. | |
